AD824ARZ-14

single supply amplifier, 18 V, 2 pA, 2 MHz, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~3.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.00~3.50

PartNumber:: AD824ARZ-14

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. penny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-01

From Other Seller

Part Number:AD824ARZ-14
US $2.00 - 3.50
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD824ARZ-14 is a quad, FET input, single supply amplifier, featuring rail-to-rail outputs. The combination of FET inputs and rail-to-rail outputs makes the AD824ARZ-14 useful in a wide variety of low voltage applications where low input current is a primary consideration. The AD824ARZ-14 is guaranteed to operate from a 3 V single supply up to ±15 volt dual supplies. Fabricated on ADIs complementary bipolar process, the AD824ARZ-14 has a unique input stage that allows the input voltage to safely extend beyond the negative supply and to the positive supply without any phase inversion or latchup. The output voltage swings to within 15 millivolts of the supplies. Capacitive loads to 350 pF can be handled without oscillation.

Parametrics

AD824ARZ-14 absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Input Voltage: -VS - 0.2 V to +VS; (3)Differential Input Voltage: ±30 V; (4)Output Short Circuit Duration to GND: Indefinite; (5)Storage Temperature Range N, R Package: -65℃ to +150℃; (6)Operating Temperature Range: -40℃ to +85℃; (7)Junction Temperature Range N, R Package: -65℃ to +150℃; (8)Lead Temperature Range (Soldering, 60 sec): +300℃.

Features

AD824ARZ-14 features: (1)Single Supply Operation: 3 V to 30 V; (2)Very Low Input Bias Current: 2 pA; (3)Wide Input Voltage Range; (4)Rail-to-Rail Output Swing; (5)Low Supply Current: 500 mA/Amp; (6)Wide Bandwidth: 2 MHz; (7)Slew Rate: 2 V/ms; (8)No Phase Reversal.
