Product Summary

The max1483csa is a low-power transceiver for RS-485 and RS-422 communication. The device features slew-rate-limited drivers that minimize EMI and reduces reflections caused by improperly terminated cables. Data rates are guaranteed up to 250kbps. The max1483csa draws only 20μA of supply current. Additionally, it has a low-current shutdown mode that consumes only 0.1μA. Both parts operate from a single +5V supply. The applications of the max1483csa include Low-Power RS-485/RS-422 Networks, Transceivers for EMI-Sensitive Applications, Industrial-Control Local Area Networks, Large 256-Node LANs.

Parametrics

max1483csa absolute maximum ratings: (1)Supply Voltage (VCC): 7V; (2)Control Input Voltages (RE, DE): -0.5V to (VCC + 0.5V); (3)Driver Input Voltage (DI): -0.5V to (VCC + 0.5V); (4)Driver Output Voltages: -7.5V to 12.5V; (5)Receiver Input Voltages (A, B): -7.5V to 12.5V; (6)Receiver Output Voltage (RO): -0.5V to (VCC + 0.5V); (7)Continuous Power Dissipation (TA = +70℃); (8)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; 14-Pin Plastic DIP (derate 10.00mW/℃ above +70℃): 800mW.

Features

max1483csa features: (1)Low 20μA Operating Current; (2)Slew-Rate Limited for Reduced EMI and Reduced Reflections; (3)0.1μA Low-Current Shutdown Mode; (4)Designed for RS-485 and RS-422 Applications; (5)Operate from a Single +5V Supply; (6)-7V to +12V Common-Mode Input Voltage Range; (7)Allows up to 256 Transceivers on the Bus. Guaranteed (1.8-unit load); (8)Current Limiting and Thermal Shutdown for Driver Overload Protection.
