Product Summary

The A80486DX2-66 is a high-performance, clock-selectable, 3.3V, 32-bit microprocessor. It provides optimal price/performance for high-end 486 power-managed systems. The A80486DX2-66 offers superior local bus graphics performance for microsoft windows. The A80486DX2-66 operates with 1X clock input. This 1X clock simplifies system design by reducing the clock frequency required by external devices.

Parametrics

A80486DX2-66 absolute maximum ratings: (1)Case temperature under bias: -65℃ to 110℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to groud: -0.5V to VCC +2.6V; (4)Supply voltage with respect to Vss: -0.5V to +4.6V.

Features

A80486DX2-66 features: (1)Operating voltage range 3.3V±0.3V; (2)High integration on-chip; (3)High-performance design; (4)Complete 32-bit architecture; (5)Multiprocessor support; (6)Standard 168-pin PGA package; (7)Supports environmental protection agency’s energy star program.

Diagrams

A80486DX2-66 block diagram
