Product Summary

The TAJB156K010RNJ is a standard tantalum with general purpose SMT chip tantalum series, 6 case sizes and low profile options. There are some applications of this device including high frequency circuit board, Cell Phone, Mp3, Mp4, PC, CD-ROM, living appliances, OA appliances, TV, VCR, Battery, Electric circuits, Digital circuits, etc.

Parametrics

Technical specifications: (1)Technical Data: All technical data relate to an ambient temperature of +25°C; (2)Capacitance Range: 0.10 μF to 2200 μF; (3)Capacitance Tolerance: ±10%; ±20%; (4)Rated Voltage (VR)≤ +85°C: 2.5, 4, 6.3, 10, 16, 20, 25, 35, 50, 63; (5)Category Voltage (VC)≤ +125°C: 1.7 2.7 4 7 10 13 17 23 33 42; (6)Surge Voltage (VS)≤ +85°C: 3.3, 5.2, 8, 13, 20, 26, 32, 46, 65, 82,; (7)Surge Voltage (VS)≤ +125°C: 2.2, 3.4, 5, 8, 13, 16, 20, 28, 40, 50; (8)Reliability: 1% per 1000 hours at 85°C, VR with 0.1Ω/V series impedance, 60% confidence level; (9)Qualification: CECC 30801 - 005 issue 2 EIA 535BAAC; (10)Termination Finished: Sn Plating (standard), Gold and SnPb Plating upon request Meets requirements of AEC-Q200.

Features

Features: (1)General purpose SMT chip tantalum series; (2)6 case sizes available; (3)Low profile options available; (4)CV range: 0.10-2200μF / 2.5-50V.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TAJB156K010RNJ
TAJB156K010RNJ
AVX
Tantalum Capacitors - Solid SMD 10volts 15uF 10%
Data Sheet
0-1: $0.60
1-100: $0.32
100-200: $0.27
200-500: $0.24
